MAXRAMPS 5" DRIVE-UP LIFT RAMPS WITH HOOK are designed to create a low-angle transition onto compatible four-post lifts using an integrated metal hook that connects directly to the lift's ramp slot. With a shallow 6.5-degree approach, 5-inch lift height, and 14-inch-wide body, they're built for performance and classic vehicles that need more clearance than factory lift ramps provide.

Key Features & Benefits

🔹 Integrated Metal Hook Connection – Designed to interface directly with the hook slot on compatible four-post lifts.

🔹 Ultra-Gentle 6.5° Approach – Helps low-clearance vehicles transition onto the lift without scraping or high-centering.

🔹 5" Transition Height – Intended for four-post lifts with a minimum resting height of approximately 5 inches.

🔹 Wide 14" Ramp Body – Supports recommended tire widths up to 12 inches.

🔹 Lightweight but Strong – Each ramp weighs only 8.5 lbs. while supporting 1,750 lbs.

How to Use

Step 1: Measure the hook slot on your four-post lift and verify compatibility before use.

Step 2: Engage the MaxRamps metal hook securely with the lift's hook slot.

Step 3: Confirm that both ramps are aligned and fully seated.

Step 4: Slowly drive the vehicle onto the 6.5-degree ramps and continue onto the lift.

Pro Tip: Fitment matters on this model. The hook extends 3.5 inches from the ramp, has a 90-degree downturn, and is 8 inches wide. Measure your lift before ordering rather than assuming all four-post hook systems are identical.

Why We Love It

We think the hook design is the cleanest MaxRamps solution when your lift is built to accept it. Instead of resting against or underneath the factory ramp, the integrated metal connection creates a more defined transition point, and the 6.5-degree incline is exceptionally friendly to low cars.

Compatible With / Works Best With

✅ Compatible Four-Post Lifts – Designed for lift systems using the appropriate hook-style ramp slot.

✅ Lowered & Performance Vehicles – 6.5-degree approach helps protect low front and underbody components.

✅ Classic Cars with Low Headers – Reduces the breakover angle that can cause underbody contact.

Frequently Asked Questions

❓ Will this fit every four-post lift?

💡 No. You should verify your lift's hook-slot dimensions before ordering.

❓ What are the hook dimensions?

💡 The hook extends approximately 3.5 inches, has a 90-degree downturn, and is 8 inches wide.

❓ What is the approach angle?

💡 6.5 degrees.

❓ What is the maximum tire width?

💡 12 inches. MaxRamps also offers a wider version for tires up to 18 inches.

❓ How much does each ramp weigh?

💡 Approximately 8.5 lbs.

Technical Specifications

📏 Dimensions: 48" L x 14" W

⬆️ Lift Height: 5"

📐 Approach Angle: 6.5°

⚖️ Load Capacity: 1,750 lbs. Each / 3,500 lbs. per Pair

🛞 Maximum Tire Width: 12"

🔩 Hook: 3.5" Extension / 90° Downturn / 8" Wide

🏋️ Weight: 8.5 lbs. Each

🧱 Construction: Solid-Core High-Density EPS with Polyurea Coating

📦 Included: 2 Ramps

Made in the USA

Warranty Information

Backed by a 12-month limited manufacturer warranty covering defects in materials and workmanship under normal use.
